PVE37 Serving Pittsburgh, Buffalo, Rochester, Syracuse, Erie, and Surrounding Areas

Standard Features:

• No pit, hoist way, or machine room required
• Self supporting structure
• 35 ft total rise Max
• 30 ft/min travelling speed
• Two to Four stops
• External cylinder diameter: 37 inches (933mm)
• Internal cabin diameter: 32 inches (813mm)
• Internal cabin height: 6’5” (77 inches/ 1956mm)
• Entrance way opening: 21 inches (534mm)
• Weight of unit: 1,100 lbs for 2 stop w/ 9’ ceilings
• Through Floor or Balcony Mount Landings
• Power Supply: 30 AMP 220VAC
• In-line and 180° door openings
• Aluminum and polycarbonate cylinder structure
• Automatic interior LED lighting and fan
• Mechanical emergency safety brake system
• One year limited manufacturer warranty
• ASME A17.7 Certified

Options:

• Colors: Standard Dark Gray, Light Gray, and White
• Phone
• Foldable Cabin Seat
• Cabin Key Lock
• Earthquake Brackets

Drawing & Specs:

2 Stop 3 Stop 4 Stop Technical Specs
