Hydraulic Home Elevators
Serving Pittsburgh, Buffalo, Rochester, Syracuse, Erie, West Virginia, & Surrounding Areas
Why Architects and Builders Choose Hydraulic Home Elevators
Hydraulic home elevators are one of the most specified residential drive systems. Their proven reliability, smooth operation, and predictable installation requirements make them a dependable choice for both new construction and retrofit projects. At a glance, you can expect:
- Travel speed: 40 FPM
- Rated capacity: 1,000 lbs
- Motor: 3 HP hydraulic drive
- Maximum travel: 50 ft. / up to 6 stops
- Machine room: Required, adjacent to hoistway
- Power: 208/230 VAC, 30-amp, single-phase
- Minimum overhead: 96″ with standard 7’0″ interior car height
- Pit depth: 6″ minimum (8″ preferred)
- Cab size: Up to 18 sq. ft. with custom car heights
- Warranty: 3-year limited factory parts
- Standards: ASME A17.1 Section 5.3
The Cibes Symmetry hydraulic residential elevator we install is custom-built in the United States with cab sizes up to 18 square feet, multiple panel styles, and a full range of wood finishes, door configurations, and fixture options.
Let’s Plan Your Next Elevator Project
Whether you’re designing new construction or evaluating a retrofit, the Access Elevator team brings over 55 years of installation experience to help you get it right.
How Hydraulic Home Elevators Work
Our hydraulic elevators for home use operate on a simple, time-tested principle. An electric pump fills a sealed cylinder with hydraulic fluid, driving a piston upward to raise the cab. To descend, a valve gradually releases pressure for a controlled, gentle lowering. The result is one of the smoothest, quietest rides available in residential elevator technology.
Built-In Safety Your Family Can Trust
Every hydraulic home elevator we install comes standard with multiple layers of protection:
- Rupture valve to prevent free-fall
- Light curtain sensors monitoring the car entrance
- Slack rope safety device
- Emergency stop switches inside the cab
- Battery-backup lighting and alarm
- Electromechanical door interlocks
For a home elevator for elderly family members, these are important standards on every unit.
Designed to Fit Your Home
One of the biggest concerns families have is whether their home can handle the installation. In most cases, the answer is yes.
- The hoistway and cab occupy roughly 20 square feet
- The machine room can be tucked into a garage, utility room, or storage area within 40 feet of teh hydraulic cylinder
- Pit depth starts at just 6 inches
- Minimum overhead is 96 inches with a standard car height, no overhead traction equipment needed
These minimal footprint demands make hydraulic home elevators one of the best home elevators for aging in place, even in older homes across our service area.
Long-Term Reliability, Low-Maintenance Ownership
Hydraulic systems have fewer moving parts than traction-based alternatives, which means less wear and lower service costs over time. In the event of a power outage, the battery backup safely lowers the cab to the nearest landing. Our maintenance plans are designed to keep your quiet home elevator hydraulic system running trouble-free for years.
Is Hydraulic the Right Drive for Your Home?
Our hydraulic drive is an excellent fit if you:
- Live in a home with more than two levels
- Need to accommodate a wheelchair or mobility device
- Want the quietest possible ride
- Value proven, low-maintenance technology
If space for a machine room is limited or you only need two stops, an inline gear drive (which has the capbiliteis of six stops) or the Ascenda shaftless elevator may be a better fit.
The Region’s Most Trusted Residential Elevator Installers
As one of the most experienced residential elevator installers in West Virginia, Pittsburgh, Buffalo, and the surrounding areas, Access Elevator has been delivering aging in place elevator solutions to families since 1969. Let us help you find the right hydraulic home elevator for your home, your family, and your budget.
Call today for your complimentary site evaluation: 888-668-LIFT (5438)
Frequently Asked Questions About Hydraulic Home Elevators
How much space does a hydraulic home elevator require?
The cab and hoistway take up about 20 square feet—roughly a 4′ × 5′ footprint. You’ll also need a small machine room (approximately 4′ × 4′) adjacent to the shaft. Many homeowners place it in a garage, utility closet, or storage area to minimize the impact on living space.
What happens during a power outage?
Every hydraulic home elevator we install includes a battery backup system, known as an uninterruptable power supply, that safely lowers the cab to the nearest landing and opens the doors so passengers can exit. No one gets stranded.
How does a hydraulic elevator compare to an inline gear drive or shaftless model?
Hydraulic drives offer the quietest ride, the same capacity, and support the same number of stops. An inline gear drive eliminates the need for a machine room, and a shaftless elevator is ideal for two-stop applications in tighter spaces. Our team can help you determine which system is the best match during a complimentary site evaluation.
